Connecting the storage system to an application server
Scenario 1 Directly connecting host ports to the application server
Application
server
Application
server
Controller
enclosure
Controller
enclosure
The controller enclosure can connect to application servers through 1 Gbit/s iSCSI, 10 Gbit/s TOE, 10 Gbit/s
FCoE, 8 Gbit/s FC, and 16Gbit/s FC host ports.
iSCSI cable connection
Optical fiber cable connection
