Scenario 2 Connecting host ports to the application server through switches
iSCSI cable connection
Optical fiber cable connection
Application
server
Ethernet
switch
Ethernet
switch
Controller
enclosure
Application
server
Controller
enclosure
Fibre Channel
switch
Fibre Channel
switch
20
