Unboxing your Phone
4
Unboxing your Phone
Inserting a SIM card and microSD card
Your phone's 2-in-1 card slot is located on the upper left side of the phone. You can
insert 2 nano-SIM cards, or 1 nano-SIM card and 1 microSD card.
Tips:
Your phone only supports nano-SIM cards. Contact your carrier for a new or
replacement nano-SIM card.
Only use standard nano-SIM cards to avoid damaging the SIM card tray.
Ensure that the card is in the correct position and keep the card tray level when
inserting it into your phone.
Be careful not to hurt yourself or damage your phone when using the SIM eject pin.
Store the SIM eject pin out of the reach of children to prevent accidental swallowing or
injury.
1
Press and hold the power button, and then select to turn off your phone.
2
To remove the card tray, insert the SIM eject PIN included with your phone into the
small hole next to the card tray.
3
Insert a SIM card or microSD card into the card tray.
4
Insert the card tray back into your phone in the correct orientation.
Charging your phone
Your phone comes with a long-lasting battery and efficient power-saving technology.
This section outlines how to care for your battery in order to maximize its lifespan.
Using your battery
You can recharge your battery many times, but all batteries have a limited lifespan. If
you notice a significant deterioration in your phone's battery life, contact an

Table of Contents

Other manuals for Huawei P9 LITE

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei P9 LITE and is the answer not in the manual?

Huawei P9 LITE Specifications

General IconGeneral
Display diagonal5.2 \
Orientation sensor-
Audio formats supportedAAC, AMR, AWB, FLAC, MID, MP3, MP4, OGG, WAV
Video formats supported3GP, MKV, MP4, WEBM
Processor cores4
Processor familyHi-Silicon
Processor frequency2 GHz
Coprocessor frequency1.7 GHz
Processor lithography16 nm
Coprocessor architectureARM Cortex-A53
RAM capacity3 GB
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Internal storage capacity16 GB
Flash typeLED
Front camera typeSingle camera
Rear camera resolution (numeric)13 MP
Front camera resolution (numeric)8 MP
Battery capacity3000 mAh
2G standardsGSM
3G standardsUMTS
SIM card typeNanoSIM
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
3G bands supported900, 1900, 2100 MHz
SIM card capabilitySingle SIM
2G bands (primary SIM)850, 900, 1800, 1900 MHz
Mobile network generation4G
Graphics cardMali T830
Graphics & IMC lithography28 nm
USB connector typeMicro-USB
HDMI ports quantity0
Headphone connectivity3.5 mm
Form factorBar
Product colorWhite
PlatformAndroid
Operating system installedAndroid 6.0
Storage temperature (T-T)-20 - 45 °C
Operating temperature (T-T)0 - 35 °C
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth7.5 mm
Width72.6 mm
Height146.8 mm
Weight147 g
