Huawei P9 LITE User Manual

Settings
175
• Press and hold the power button, and then touch Airplane mode .
• Open Settings , and then turn on the Airplane mode switch.
When airplane mode is on, is displayed in the status bar.
Using the floating dock
The floating dock gives you access to a number of frequently-used options and features,
such as the back key, home key, and one-touch optimization. You can move the floating
dock around the screen for easy one-hand use.
Open Settings . Touch Smart assistance > Floating dock and then turn on the Floating
dock switch.
Once enabled, the floating dock button ( ) will be shown on all screens except the
lock screen and notification panel. Touch to expand the floating dock menu.

Huawei P9 LITE Specifications

General

Display diagonal	5.2 \
Orientation sensor	-
Audio formats supported	AAC, AMR, AWB, FLAC, MID, MP3, MP4, OGG, WAV
Video formats supported	3GP, MKV, MP4, WEBM
Processor cores	4
Processor family	Hi-Silicon
Processor frequency	2 GHz
Coprocessor frequency	1.7 GHz
Processor lithography	16 nm
Coprocessor architecture	ARM Cortex-A53
RAM capacity	3 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Internal storage capacity	16 GB
Flash type	LED
Front camera type	Single camera
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	8 MP
Battery capacity	3000 mAh
2G standards	GSM
3G standards	UMTS
SIM card type	NanoSIM
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
3G bands supported	900, 1900, 2100 MHz
SIM card capability	Single SIM
2G bands (primary SIM)	850, 900, 1800, 1900 MHz
Mobile network generation	4G
Graphics card	Mali T830
Graphics & IMC lithography	28 nm
USB connector type	Micro-USB
HDMI ports quantity	0
Headphone connectivity	3.5 mm
Form factor	Bar
Product color	White
Platform	Android
Operating system installed	Android 6.0
Storage temperature (T-T)	-20 - 45 °C
Operating temperature (T-T)	0 - 35 °C
Cables included	USB

Weight and Dimensions

Depth	7.5 mm
Width	72.6 mm
Height	146.8 mm
Weight	147 g
