Table B-5 Contents of engineering labels for trunk cables between devices
Content Meaning Example
MN-B-C-D-
R/T
MN: cabinet
number
For example, A01.
B: chassis
number
Numbered in the bottom-up order with two digits, for
example, 01.
C: physical slot
number
Numbered in the left-right and top-bottom order with two
digits, for example, 01.
D: interface
number
Numbered with two digits in the top-bottom and left-
right order. For example, 01.
R: optical
receiving
interface, T:
optical transmit
interface.
-
MN-B-C-D-
R/T
MN: cabinet
number
For example, A01.
B: chassis
number
Numbered in the bottom-top order with two digits, for
example, 01.
C: physical slot
number
Numbered in the left-right and top-bottom order with two
digits, for example, 01.
D: interface
number.
Numbered with two digits in the top-bottom and left-
right order. For example, 01.
R: optical
receiving
interface, T:
optical transmit
interface.
-
Example of the Label
Figure B-12 shows the label on the cable.
Figure B-12 Engineering labels for trunk cables between devices
G01
T
TO:
01 05 01
D02
R
01
01
01
Meaning of the label in Figure B-12 is as follows:
B Engineering Labels for Cables
Quidway S5300 Series Ethernet Switches
Quick Start
B-16 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2008-12-26)
