Huawei S1720 Series Hardware Description

NOTE
All the optical ports on the ES5D21Q04Q01 support only QSFP+ optical modules and QSFP+ copper
cables.
Table 5-5 Attributes of a QSFP+ optical port
Attribute Description
Connector type LC/MPO
Optical port attributes Depend on the optical module used (see 7.4.3
QSFP+ Modules)
Standards compliance IEEE 802.3ba
5.2.5 Specifications
Table 5-6 lists specifications of the ES5D21Q04Q01.
Table 5-6 Specifications of the ES5D21Q04Q01
Item Description
Physical
specifications
l Dimensions (W x D x H): 100 mm x 208 mm x 40 mm
l Weight: 0.5 kg
l Maximum power consumption: 18.83 W
Environment
parameters
l Operating temperature: 0°C to 45°C
l Relative humidity: 5% RH to 95% RH
l Storage temperature: -40°C to +70°C
5.2.6 Ordering Information
Card ordering information is subject to updates with product version upgrades. The ordering
information provided in this manual is for reference only. To obtain latest ordering information,
contain Huawei switch distributors or Huawei local office.
Table 5-7 provides ES5D21Q04Q01 ordering information.
Table 5-7 ES5D21Q04Q01 ordering information
Card Description Card Name Part Number
4-port 40 Gig QSFP+
interface card
ES5D21Q04Q01 03022RRP
S6700 Series Ethernet Switches
Hardware Description 5 Cards
Issue 12 (2015-07-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
63

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
