Huawei S5700 Series User Manual

Table 2-7 Description of S5700-24TP-SI-AC indicators
No. Indicator Identifier Status Description
1 Power
indicator
PWR Off The switch is powered
off.
Green The switch is powered
on.
Orange The power supply unit is
faulty, and the external
RPS system has started.
2 RPS
indicator
RPS Off The RPS is not
connected to the switch
or the RPS is faulty.
Green The RPS is connected to
the switch.
3 System status
indicator
SYS Off The system is not
operating.
Green The system is not
operating properly or is
starting.
Orange The system is
performing self-check
during startup.
Blinking green The system is operating
properly.
Red After registering, the
system does not operate
properly, or a power
alarm, fan alarm, or
temperature alarm is
generated.
4 Mode
indicator
- Off The service interface
indicator is in the default
mode (STAT).
Green The service interface
indicator indicates the
interface speed. After 45
seconds, the service
interface indicator
automatically restores to
off.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 2 Product Hardware Introduction
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
