Figure 5-3 Specifying parameters
Table 5-1 Parameters
Parameter
Value
Bit per second (baud rate) 9600
Data bit 8
Parity check None
Stop bit 1
Flow control (traffic control) None
Step 5 After the HyperTerminal starts, choose FileAttributes to display the COMM1 Properties
dialog box, as shown in Figure 5-4. On the Setting tab, select VT100 in the Emulation drop-
down list box. Click OK to complete the setting.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 5 Logging in to the Device
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
57
