Huawei SUN2000-12KTL Quick Installation Guide

9
Main menu
screen
Quick
settings
•
The preset passwords for Common User, Advanced User, and Special User are 00000a.
•
Use the preset password upon initial login. To ensure account security, change the password
immediately after login.
•
The screen snapshots in this document correspond to app 2.2.00.035 (Android).
•
Set the correct grid code based on the application region and scenario of the SUN2000.

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
