Figure 5-4 Opening the maintenance compartment door
Step 3 Remove the accessories that are bound in the maintenance compartment for
future use.
For some models, a three-hole rubber plug is bound in the maintenance compartment.
After removing the rubber plug, save it properly for future use.
Figure 5-5 Removing the accessories from the maintenance compartment
(1) Crimping modules
----End
SUN2000-(196KTL-H0, 200KTL-H2, 215KTL-H0)
Series
User Manual 5 Electrical Connections
Issue 08 (2021-09-30) Copyright © Huawei Technologies Co., Ltd. 34
