Huawei TMC11H - Advanced Service Cable Installation; Installing IF Cables; Installing Optical Fibers

27
4
Installing Service Cables of the Devices
E1 cable (adapter cable)
E1 cable (output cable)
Ethernet cable (adapter cable)
Ethernet cable (output cable)
IF cable
Optical fiber
Monitoring cable
• The service cables in the AMP30H/TMC11H cabinet are routed in the same way.
• When the RTN 900 and the wireless equipment are installed in the same cabinet,
the E1 and Ethernet cables do not need to be connected to the surge protection
box and are directly connected to the peer equipment.
