Acronym Display Description
DHP Dynamic Host
Conguration Protocol
(DHCP)
IP ADS IP address
SUB NET Subnet mask
GAT UAY Gateway
NBA No battery alarm
disabled
5.4 Buttons
The control panel provides three buttons to start and shut down the UPS, and
view and set parameters.
Figure 5-2 Buttons on the UPS control panel
UPS2000-A-(1 kVA-3 kVA)
User Manual 5 Setting Control Panel
Issue 17 (2024-01-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 48
