Supported 5 GHz channels: channels 36–64 and 100–140 in countries and areas using
the CE standards, and channels 36–64, 100-140 and 149–165 in countries and areas
using the FCC standards.
⚫
Channel values vary with countries.
⚫
Currently, the router does not support the 5 GHz DFS channel in countries and areas using the FCC
standards.
⚫
Relationship between 5 GHz channels and frequency bands: Channels 36–48 correspond to band 1
(5.15–5.25 GHz). Channels 52–64 correspond to band 2 (5.25–5.35 GHz) DFS. Channels 100–140
corresponds to band 3 (5.47–5.725 GHz) DFS. Channels 149–165 correspond to band 4 (5.725–5.85
GHz).
3.2 Ports
10/100/1000 Mbit/s WAN/LAN auto-adaptation Ethernet port: 4
3.3 Power Supply Specification
WS7206-20
⚫
Power supply: 12V DC, 1 A
⚫
Power consumption: < 12W
⚫
Input voltage: 100 - 240V AC
⚫
Input voltage frequency: 50 – 60 Hz
WS7206-30
⚫
Power supply: 12V DC, 2 A
⚫
Power consumption: < 24W
⚫
Input voltage: 100 - 240V AC
⚫
Input voltage frequency: 50 – 60 Hz
3.4 Physical Specifications
⚫
Dimensions (Height x Width x Depth):
The product with folded external antennas: 39.7mm x 225mm X159.2mm
The product with vertical external antennas: 161.1 mm X 225mm X169.38mm
The packaging of EU/US version: 56mm x 313mm x 212mm
⚫
Weight:
The product without packaging: about 403g
The EU version weight: about XXXg
The US version weight: about XXXg
⚫
Operating temperature: 0°C to 40°C (32°F to 104°F)
