13
Model kW
Volts/
Phase Amps
Min.
Breaker
Size
Wire
Size
Conduit
Size
Wiring
Diagram
Element
AmpDraw
TX008‐2RS 8 208/1 38.5 45 8 ¾" 1 19.9
TX011‐3R 11 208/3 30.5 35 8 ¾" 3 16.3
TX011‐2S 11 240/1 45.8 50 8 ¾" 1 22.9
TX011‐3T3 11 380/316.7 20 8 ¾" 4 9.9
TX012‐2RS 12 208/1 57.7 70 6 ¾" 1 28.9
TX012‐3R 12 208/3 33.3 35 8 ¾" 3 19.9
TX013‐3T3 13 380/3 19.8 25 8 ¾" 4 11.5
TX013‐3T7 13 415/3 18.1 20 8 ¾" 4 10.8
TX014‐2RS 14 208/1 67.3 80 4 1" 1 32.5
TX014‐2S 14 240/1 58.3 70 6 ¾" 1 29.2
TX014‐3T 14 240/3 33.7 40 8 ¾" 3 18.8
T
X
015‐3T3 15 380/3 22.8 25 8 ¾" 4 13.2
TX016‐3RS 16 208/1 76.9 90 4 1" 2 25.3
TX016‐3R 16 208/3 44.4 50 8 ¾" 3 25.3
TX016‐2S 16 240/1 66.7 80 4 1" 1 33.3
TX016‐3T 16 240/3 38.5 45 8 ¾" 3 22.9
TX016‐3T7 16 415/3 22.3 25 8 ¾" 4 12.6
TX018‐3RS 18 208/1 86.5 100 3 1" 2 28.9
TX018‐3R 18 208/3 50.0 60 6 ¾" 3 28.9
TX018‐2S 18 240/1 75.0 80 4 1" 1 37.5
TX018‐3T3 18 380/3 27.3 30 8 ¾" 4 15.7
TX018‐3T7 18 415/3 25.0 30 8 ¾" 4 14.4
TX018‐3T4 18 480/3 21.7 25 8 ¾" 4 12.5
TX020‐3RS 20 208/1 96.2 110 2 1" 2 32.5
TX020‐3R 20 208/3 55.5 60 6 ¾" 3 32.5
TX020‐3T3 20 380/3
3
0.4 35 8 ¾" 4 17.7
TX020‐3T7 20 415/3 27.8 30 8 ¾" 4 16.2
TX021‐3S 21 240/1 87.5 100 3 1" 2 29.2
TX021‐3T 21 240/3 50.5 60 6 ¾" 3 29.2
TX021‐3T4 21 480/3 25.3 30 8 ¾" 4 14.6
TX021‐3T6 21 600/3 20.2 25 8 ¾" 5 20.2
TX024‐6RS 24 208/1 115.4 125 1 2" 6 19.9
TX024‐6R 24 208/3 66.6 70 4 1" 7 19.9
TX024‐3S 24 240/1 100.0 110 2 1" 2 33.3
TX024‐3T 24 240/3 57.7 70 6 ¾" 3 33.3
TX024‐3T7 24 415/3 33.4 40 8 ¾" 4 19.3
TX024‐3T4 24 480/3 28.9 35 8 ¾" 4 16.7
TX024‐3T6 24 600/3 23.1 25 8 ¾" 5 23.1
TX025‐3T3 25 380/3 38.0 40 8 ¾" 4 22.2
TX027‐3S 27 240/1
112.5 125 1 2" 2 37.5
TX0
27‐3T 27 240/3 65.0 70 4 1" 3 37.5
TX027‐6T3 27 380/3 41.0 45 8 ¾" 9 11.5
TX027‐6T7 27 415/3 37.6 40 8 ¾" 9 10.8
TX027‐3T4 27 480/3 32.5 35 8 ¾" 4 18.8
