SECTION VII – PARTS LIST
Category Description Hubbell P/N
Plumbing Quick-Connect -Inlet, 3/4" C x 3/4" MNPT LF4501B-1412
Quick-Connect-Outlet 3/4" C x 3/4" C LF4515B-14
Quick-Connect-Inlet/Outlet 1" C x 1"FNPT LF4510B-1816
Heating Chamber: 3 Element, Low Flow TK3-FM
Heating Chamber: 3 Element, High Flow TK3-FMHF
Heating Chamber: 6 Element, Low Flow TK6-FM
Heating Chamber: 6 Element, High Flow TK6-FMHF
Filter Screen for Inlet SCREEN T
K
Elements 4500 Watts @ 240 Volts, 8.5" long
N
1315-4500
(with O-ring) 5500 Watts @ 240 Volts, 8.5" long
N
1315-5500
7000 Watts @ 240 Volts, 12" long
N
1315-7000
8000 Watts @ 240 Volts, 12" long
N
1375-8000
9000 Watts @ 240 Volts, 12" long
N
1375-9000
6000 Watts @ 480 Volts, 12" long
N
1315-6000T4
7000 Watts @ 480 Volts, 12" long
N
1315-7000T4
8000 Watts @ 480 Volts, 12" long
N
1375-8000T4
9000 Watts @ 480 Volts, 12" long
N
1375-9000T4
7000 Watts @ 440 Volts, 12" long
N
1315-7000T5
8000 Watts @ 440 Volts, 12" long
N
1375-8000T5
9000 Watts @ 440 Volts, 12" long
N
1375-9000T5
7000 Watts @ 346 Volts, 12" long
N
1315-7000T6
8000 Watts @ 346 Volts, 12" long
N
1375-8000T6
9000 Watts @ 346 Volts, 12" long
N
1375-9000T6
8000 Watts @ 208 Volts, 12" long
N
1375-8000
R
Extra O-Ring O RING SGB
Electrical Thermistor (with wire leads) USP9509
Auto Reset Hi-Limit 200°F (with wire leads)
L93
Temperature Control Board TK2000
Digital Display TKD2000
Power Distribution Block: 3 Pole 16023-3
Power Distribution Block: 2 Pole 67512
Transformer, 50VA, 380V - 185V B050-3351-3
Transformer, 50VA, 480V - 208V B050-3299-3
Transformer, 50VA, 600V - 195V B050-3350-3
Magnetic Contactor, 40A (Res.), 208/240V Coil C25DNF330B
Magnetic Contactor, 50A (Res.), 208/240V Coil C25DNF340B
Magnetic Contactor, 65A (Res.), 208/240V Coil C25DNF350B
Magnetic Contactor, 75A (Res.), 208/240V Coil C25FNF360B
Magnetic Contactor, 90A (Res.), 208/240V Coil C25FNF375B
Triac, 600V (with wire leads) TG40E60
Triac, 800V (with wire leads) TG40E80
Flow Meter (1/2" NPT, 0.2-8 GPM) TK FLOW B
R
Flow Meter (1" NPT, 0.5-40 GPM)
VT2511MSHNP000
Miscellaneous Overlay cover for TKD2000
TANKLESS OVERLAY
