Hubsan ACE PRO - Page 8

2
Bind button
16
TF Slot
18
Video transmission indicator
17
Battery buckle
19
Note: The aircraft generates heat during operation.
Please avoid direct touch the ventilated rib on the
bottom of the aircraft after the flight.
Auxiliary Light
Downward Vision System
Infrared Assisted Altitude System
21
22
23
16
17
18
19
Cooling fan20
22
20
23
21
