212 Series Tooling Alcoa Fastening Systems
29
No. P/N Qty Description
50 116585 1 Muffler End Cap
51 504127 3 Screw-Button Hd.- -10-32 x 5/8 long
52 115558 1 Throttle Valve Assem. (incI. 28, 53, 54)
53* 504407 1 O-ring
54* 504408 2 O-ring
55 120588 1 Anvil Stop
56 123149 1 Damper
57 Not Used - - - - - -
58 115504 1 Bushing Upper
59 115503 1 Bushing Lower
60 115436 1 Air Hose
61 121377 1 Damper Tube
62 122432 1 Gland Cap
63* 506654 1 Washer
64* 506653 1 Retaining Ring
(1) For replacement of machined handle/head only, Handle/head, 119653 and Bleed Plug
Assembly, 104293 are required.
(2) When Bleed Plug Assem. 104293, has been removed and reinstalled in tool 5 times,
NYLOK locking element in plug becomes worn out, therefore, worn out bleed plug must
be replaced with new plug to prevent hydraulic fluid loss.
Rev 6-20-94 includes:
(29)(32)(33)(34)(35)
Rev 9-1 -94 includes:
(6)(7)(42)(43)(56)(63)(64)
PARTS LIST (CONT.)
