Huck ALCOA 212 - Parts List

212 Series Tooling Alcoa Fastening Systems
27
Ref. P/N Qty. Description
1 100534-1 1 Pintail Tube
2 111795 1 Retaining Nut
3 119653 1 Handle/head (see footnote 1)
4 104293 1 Bleed Plug Assem. (incl. ref. 5; see footnote 1)
5* 505438 1 O-ring
6 120827 1 Piston Assembly (incl. ref. 7, 63, 64)
7* 505865 1 POLY-SEAL
8 122430 1 Front Gland Assembly (incI. 9,10,61)
9* 503806 1 O-ring
10* 505827 1 POLY-SEAL
11* 505817 1 Wiper
12 Not Used - - - - - -
13 505946 1 Spring
14 119658 1 End Cap
15 Not Used - - - - - -
16 Not Used - - - - - -
17* 118809 1 Deflector
18 500619 1 Slotted Pin - - .125 x 5/8 long
19 116407 1 Linkage Pin
20 116262 1 Trigger
21 116404 1 Cable Assembly
22 116405 1 Throttle Arm
23 116916 1 Shoulder Screw
24 115555 1 Cylinder Assembly (incI. 25, 58, 59)
- - 501352 1 Dowel Pin (not shown)
PARTS LIST
