Huck BOBTAIL - Assembly Drawing - Hoses, Cord, and Fittings; Hose and Fitting Component Diagram

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
13
See previous page for
Tool Head and Handle
part numbers.
Apply Loctite 242,
HUCK p/n 505016,
to these threaded joints
per manufacturers
instructions.
Apply Loctite 242,
HUCK p/n 505016,
to these threaded joints
per manufacturers
instructions.
110438 Male
Hydraulic Coupler
110439 Female
Hydraulic Coupler
128938 Cord Assy
503431
Reducing Bushing
503431
Reducing Bushing
124881-6
2-Foot Hydraulic Hose
Assy with Guard
Apply Loctite 242,
HUCK p/n 505016,
to these threaded joints
per manufacturers
instructions.
Apply Loctite 242,
HUCK p/n 505016,
to these threaded joints
per manufacturers
instructions.
A
A
SSEMBLY
SSEMBLY
D
D
RAWING
RAWING
- H
- H
OSES
OSES
, C
, C
ORD
ORD
,
,
AND
AND
F
F
IRINGS
IRINGS
FIGURE 6
