SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
7
1. Attach proper Nose Components to Tool as applicable.
2. Use Huck POWERIG Hydraulic Unit, or equivalent, that
has been prepared for operation per instruction manu-
al. Check both PULL and RETURN pressures and, if
required, adjust to pressures given in
P
P
RESSURE
RESSURE
S
S
ETTINGS
ETTINGS section of this manual.
3. First, turn hydraulic unit to OFF. Then disconnect power
supply from hydraulic unit. Disconnect trigger control
system from hydraulic unit.
4. Connect PULL pressure hose, with coupler nipple, into
port “P” of tool. Use only with HUCK supplied hoses
rated at 10,000 psi or greater. Check trigger assembly
for apparent damage or wear. If required, adjust posi-
tion of trigger assembly on hose. Connect trigger con-
trol system to hydraulic unit.
5. Connect hydraulic unit to power supply (air or electric).
Turn hydraulic unit to ON. Depress trigger a few times
to cycle tool and to circulate hydraulic fluid. Observe
action of Tool and check for leaks.
P
P
REPARATION
REPARATION
FOR
FOR
U
U
SE
SE
WARNINGS:
Read full manual before using tool.
A half-hour training session with qualified
personnel is recommended before using
Huck equipment.
When operating Huck installation equip-
ment, always wear approved eye protec-
tion.
Be sure there is adequate clearance for
the operator’s hands before proceeding.
CAUTION: Do not use TEFLON
®
* tape on
pipe threads. Pipe threads may cause tape to
shred resulting in tool malfunction.
(Threadmate™ is available from Huck in a
4oz. tube as part number 508517.)
WARNING: Correct PULL and RETURN
pressures are required for operator’s
safety and for Installation TooI’s function.
Gauge T-124833CE is available for check-
ing pressures. See
P
P
RESSURE
RESSURE
S
S
ETTINGS
ETTINGS
and Gauge Instruction Manual. Failure to
verify pressures may result in severe per-
sonal injury.
WARNING: Be sure to connect Tool’s
hydraulic hoses to POWERIG Hydraulic
Unit before connecting Tool’s switch con-
trol cord to unit. If not connected in this
order, severe personal Injury may occur.
WARNING: Huck recommends that only
Huck Powerig Hydraulic Units be used as
a power source for Huck installation
equipment. Hydraulic power units that
deliver high pressure for both PULL and
RETURN, AND ARE NOT EQUIPPED
WITH RELIEF VALVES ARE SPECIFICAL-
LY NOT RECOMMENDED AND MAY BE
DANGEROUS.
Threadmate is a registered trademark of Parker Intangibles LLC.
TEFLON is a registered trademark of E. I. du Pont de Nemours and Company
CAUTION: Do not let disconnected hoses
and couplers contact a dirty floor. Keep
harmful material out of hydraulic fluid. Dirt in
hydraulic fluid causes valve failure In Tool
and In POWERIG Hydraulic Unit.
CAUTION: Hose couplers must be completely
joined together to insure that ball checks in
both nipple and body are completely open.
Improperly assembled couplers will cause
overheating and malfunctions in both tool
and Powerig. Hand tighten couplers. Do NOT
use a pipe wrench.
