14
12. To fold up the shelves:
Make sure the screws are in the slot as shown, then
slowly rotate the side shelf up.
When folding up to level position, press down the hinge
area to lock the shelf. Adjust the side shelves to align it
with the control box.
13. To remove the shelves:
Lift up the shelf, position the shelf at its fold down
position (vertical).
Align the screws with the holes on the shelf, move the
shelf from back to front until the side shelf disconnect
from the screw on the bracket.
12
Large hole
12a
Large hole
Screw
13
