Setting Up the Handlebars
Note: This procedure is for one, two and
four bolt Handlebar Stems.
1. If necessary, loosen the Handlebar
Clamp Screw(s) (A) and rotate Handle-
bar (2) into a comfortable riding posi-
tion.
2. Tighten Handlebar Clamp Screw(s) (A)
securely.
NOTE: Do not over tighten. Torque to 14-17
ft-lbs.
g 05
A
2
WARNING: If the handlebar clamp
in not tight enough, the handlebar can slip
in the stem. This can cause damage to the
handlebar or stem, and can cause loss of
control.
A
2
g 05a
3 1
2 4
2A
g 05b
Assembly
