33
Suspension Frame
(various models)
Adjustment:
The bicycle may have an adjustable shock-absorbing suspension. You can change
the suspension, as you prefer, for a softer or a fi rmer ride.
WARNING: Make sure there are at least two threads showing (C) above the
Adjusting Nut (A) so the shock does not come loose.
To change the suspension:
• For a softer ride, turn the Adjusting Nut (A) clockwise so the Suspension Spring
(B) is compressed less.
• For a fi rmer ride, turn the Adjusting Nut (A) counter clockwise so the Suspension
Spring (B) is compressed more.
A
B
C
g 25
Maintenance
