Huffy Mountain Bikes - Refl Ector Brackets Installation; Installing Derailleur Guard

19
Refl ector Brackets Installation
1. Position FRONT Refl ector (7) so it
points straight forward (fi g 10).
2. Tighten Clamp Screw.
NOTE: Do not over-tighten. This will
damage the Clamp.
g 11
10
g 10
7
1. Position REAR Refl ector (10) so it
points straight backward (fi g 11).
2. Tighten Clamp Screw.
NOTE: Do not over-tighten. This will
damage the Clamp.
Installing Derailleur Guard (on some models)
1. Remove Screws (11) from Frame Tabs (A).
2. Install Guard (12) using two Screws (11).
3. Make sure the Guard does not contact the Derailleur (B).
4. Tighten Screws (11) securely.
A
B
11
12
g 12
Assembly
