Humanscale M/Connect 2 - Mounting the Dock; Horizontal Alignment; Vertical Alignment

Horizontal Alignment
• Screw bracket (g. R) into desk underside and slide dock in
• Attach screw. (g. S) through bracket into dock to fully secure
MOUNTING THE M/CONNECT 2 DOCK
S
R
Vertical Alignment
• Screw bracket (g. T) into desk underside and slide dock in
• Attach screw. (g. U) through bracket into dock
T
U
12
