Bolt-Through Plate
3 Crossbar Link Screws4mm Hex Key
8 mm Hex Key Bolt-Through Bolts
Bolt-Through Mount
Sliding Desk Mount Clamp Mount
Crossbar Installation Hardware
4 Standard VESA Bracket
Screws
4 Plastic Spacers
4 Extended VESA Bracket
Screws
VESA Bracket and Cover
5mm Hex Key
NOTE: 4mm and 5mm Hex Key can be
found under the plastic base cover.
INSTALLATION HARDWARE
①
④
②
⑤
③
⑥
⑦ ⑧ ⑨
⑩ ⑪
⑫ ⑬
To Next Page
