Tools Required
Phillips Head Screwdriver
Assembly Instructions
1
Referencing the dimensions below for your NeatTech size, transfer the hole pattern in the hooks
to the desired location on the underside of the work surface. Install the hooks with the arrows
pointing to the front of the desk. If using a work surface:
Less than .875” in thickness use the shorter screws (#10 x 5/8”) provided
Greater than .875” in thickness use the longer screws (#10 x 1”) provided
Parts Included
1x Basket Assembly1x Set of Hooks
X2
4x #10 x 5/8” Screw
4x #10 x 1” Screw
Mini 381mm (15 in)
Small 510mm (20.08 in)
Large 650mm (25.6 in)
③
④
①
①
②
