Humanscale QUICKSTAND LITE - Tighten Shoulder Bolt; Remove Cable Cover; Remove 2.5 mm Allen Screw

5
10
Remove the cable cover from the rear of the base by sliding it up vertically and set it aside.
11
Remove 2.5 mm allen screw.
9
Tighten the bolt with the 5mm hex key. Bolt should be firm with a little bit of give. If the arm link pin
rotates as you tighten the shoulder bolt, hold it steady with your free hand.
To be fully
tightened at
a later step
QUICKSTAND LITE REWORK INSTRUCTIONS
