Humanscale QUICKSTAND LITE - Position Platform; Tighten Platform Bolt

7
15
Loosen 5mm shoulder bolt one half turn, or just until platform can be easily positioned so that it is lying
flat on a flat surface such as the desk or table.
After shoulder
screw loosened,
platform leveled
on table top
16
Once the platform is lying flat in the desired position, tighten the bolt as tight as possible with 5mm Allen
Key. If available, use a torque wrench and tighten to 15 ft. lbs.
Use free hand to
hold arm link pin
in place
QSL platform leveled
with bolt fully tightened
Leveled platform ready for
re-installation of monitors
Platform out
of level
QUICKSTAND LITE REWORK INSTRUCTIONS
