Humminbird HELIX 5 G2 SERIES User Manual

5
AutoChart Live Overview 178
Plan Your Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Prepare the Control Head for Mapping . . . . . . . . . . . . . . . . . . . .179
R
ecord your Custom Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182
Stop Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184
Correct Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184
Display/Hide your Custom Map . . . . . . . . . . . . . . . . . . . . . . . . . .185
Adjust the Map Display Settings . . . . . . . . . . . . . . . . . . . . . . . . .186
Manage your Control Head 190
Update Software 195
Maintenance 196
Troubleshooting 197
Specifications 199
Contact Humminbird 215
TABLE OF CONTENTS

Humminbird HELIX 5 G2 SERIES Specifications

General

GPS	Yes
Temperature	Yes
GPS Receiver	Internal
GPS Antenna	Internal
Power Input	10-20 VDC
Water Resistance	IPX7
Display Size	5 inches
Target Separation	2.5 inches
Depth Capability	1500 ft
Mount A Type	Gimbal Mount
Resolution	480 x 800 pixels
