2Introduction
Cables: Your MEGA 360 Imaging transducer comes with the cables required to
connect directly to your Humminbird fish finder. This includes a 10' MEGA 360 power
cable, a 10' APEX/SOLIX transducer cable, and a 10' HELIX transducer adapter cable.
However, depending on your Humminbird model and system configuration, you may
choose to purchase a transducer splitter cable (y-cable) to connect the MEGA 360 to
another compatible transducer, as shown below.
MEGA 360 compatible transducer
splitter cables (y-cables)
MEGA 360 compatible transducers
MEGA 360 7-pin Transducer Y-cable:
9 M360 2DDI Y (720107-1)
HELIX Dual Spectrum (Type 9 / 7-pin)
HELIX MDI+ (Type 9 / 7-pin)
HELIX MDI+/MSI+ (Type 9 / 7-pin)
MEGA 360 14-pin Transducer Y-cable:
14 M360 2DDI Y (720108-1)
APEX MSI+
SOLIX Dual Spectrum
SOLIX MDI+
SOLIX MDI+/MSI+
Built-in MEGA Imaging*
* If this cable is being used with a HELIX G3N/G4N with MEGA Side or Down Imaging+
and a Built-in MEGA imaging transducer, then the 720109-1 AD HELIX M360 adapter
(included with the MEGA 360) must be attached between this y-cable and the HELIX unit.
NOTE: If a MEGA SI+ transducer is connected with one of these y-cables, the
Humminbird unit will not be able to get SI data from the MEGA SI+ transducer – only HW
and MEGA DI+ will be available. However, the user can get MEGA SI data from the MEGA
360 transducer.
