1 Introduction
Introduction
The MEGA 360 Imaging Universal has a 50" shaft length and can mount to almost
any boat with the included GeigerTec aluminum bracket (select models) or a
mounting bracket of your choice. This manual will guide you through the following
installation requirements for the MEGA 360 Imaging transducer:
• Installing the MEGA 360 Universal Boat Mount (select models)
• Connecting to the Control Head and Power
• Testing the Installation
• Powering Off
Before proceeding with this installation, the Humminbird fish finder
should be installed.
Compatibility
Fish Finders: MEGA 360 Imaging Universal is compatible with the following
Humminbird fish finders:
• APEX Series
• SOLIX Series G2 and G3 models
• HELIX MEGA Imaging+ G3N and G4N models
NOTE: You must have a GPS heading sensor (compass) installed in order to use the
MEGA 360 Imaging navigation features.
NOTE: MEGA 360 Imaging can be shared with all APEX/SOLIX models and HELIX
G4N, G3N and G2N models over Ethernet.
Transducers: The MEGA 360 Imaging transducer is compatible with the following
transducers:
• HW Dual Spectrum
• HW MEGA DI+
• HW MEGA DI+/MEGA SI+
• Built-in MEGA Imaging transducer on a Minn Kota trolling motor
