Your Hunter fan comes with an integrated light xture assembly.
WARNING: Use only the light xture supplied with this fan model.
8-1. To attach the heat shield assembly, partially install two housing
assembly screws into the switch housing mounting plate.
8-2. Feed the upper plug connector through the center opening of the
shield.
8-3. Align the keyhole slots in the housing with the assembly screws.
8-4. Turn the housing counterclockwise until the housing assembly
screws are rmly situated in the narrow end of the keyhole slots.
Install the remaining screw into the housing. Tighten all three
screws rmly.
CAUTION: Make sure the heat shield assembly is securely
attached to the housing mounting plate. Failure to properly attach
and tighten all three assembly screws could result in the heat shield
assembly and light xture falling.
Steps 8-1 – 8-4
Assembly
Screw
Heat
Shield
Assembly
Note: In compliance with US federal energy regulations, this
ceiling fan contains a device that restricts the light kit to a
maximum of 190 Watts. Exceeding that limit or the marked
limit on this product may result in re hazard or improper
operation.
8 • Completing Your Installation With a Bowl Light Fixture
11
To Next Page
