9
45007-01 • 06/11/09 • Hunter Fan Company
6-1. Partially install two canopy screws (about 2 full turns) in the
hanger bracket.
6-2. Raise the canopy over the hanger bracket. Align partially installed
screws with key slots in canopy.
6-3. Twist canopy clockwise to secure.
6-4. Install third & fourth canopy screw in round hole on canopy.
Securely tighten all four screws.
6-5. Using both hands, push the canopy trim ring up to the top of the
canopy.
6-6. Twist canopy trim ring clockwise to secure the canopy.
Should you need to remove the canopy
trim ring, follow these steps:
1. Twist canopy trim ring
counterclockwise until it releases
from canopy.
Steps 6-1 – 6-2
Canopy Trim
Ring
Canopy
Hanger Bracket
Step 6-3
Canopy
Screw
Step 6-4
Step 6-5
6 • Installing the Canopy and Canopy Trim Ring
