Hunter 59126 - Installing the Canopy and Canopy Trim Ring

8
42759-01•11/28/07•HunterFanCompany
5 • Installing the Canopy and Canopy Trim Ring
5-1.Holdingthecanopy,raisethefanothehook.
5-2.Aligntheslotsinthecanopywiththetabsontheceilingplate.
5-3.Raisethecanopyovertheceilingplate.Rotatethecanopy
clockwise until the tabs on the ceiling plate totally engage with
the slots in the canopy.
5-4. Partially install the three canopy screws into the canopy one at a
time.Onceallthreescrewsarein,tightenthem.
5-5. Usingbothhands,pushthecanopytrimringuptothetopofthe
canopy. e canopy trim ring will snap and lock into place.
Should you need to remove the canopy
trim ring, follow these steps:
1. Locate the tab indicators, small
bumps on top of tabs.
2. Press firmly on opposite sides of the
ring toward the canopy. e tabs will
flex out releasing the trim ring from
the canopy.
Step 5-2
Canopy Trim
Ring
Canopy
Ceiling Plate
Step 5-3
Steps 5-4 – 5-5
Canopy
Screw
