5
ACC2 STRONGBOX PEDESTAL ASSEMBLY INSTRUCTIONS
Tools Required
• 11 mm socket wrench
• 14 mm socket wrench
• #2 Phillips head screwdriver
Assembly
Disassembling the Hunter ACC2
inner chassis: Power supply assembly
(Decoder version shown)
Step 1: Loosen the captive screws (qty: 3)
using #2 Phillips head screwdriver (Fig. 1 & 2).
Step 2: Pull the power supply assembly o and
disconnect all three connectors (Fig. 3).
Fig. 1 Fig. 2 Fig. 3
○
○
○
