3
4
Ceiling Bracket Top housing Hanging Fan Wiring Canopy Blades Light Glass/Bulbs
Check the outlet box:
Wood Screw
Installing the Top Housing
8”
3/8”
C
U
T
&
S
T
R
I
P
(not to scale)
x3
Top Housing
Screw
Grounding
Screw
bag
The wires can be cut, but
leave at least 8” extending
from the top of the canopy.
Install the top housing screws. Install
the grounding screw in the smaller
screw hole. These screws can be
found in the hardware bag.
Grounding
Screw
To prevent damage to fan,
ALWAYS lift holding the fan
housing.
Note: To hang the fan, you must tilt the canopy to
an almost vertical position so that the canopy slots
sit on the ceiling plate hooks.
Raise the fan and align the slots in the
canopy with the hooks on the ceiling plate.
Place the slots over the ceiling
plate hooks to hang the fan.
To Next Page
