Fit housing into the opening and secure by tightening the
pre-loaded screws into the joist.
Note: Install the box flush with the sheetrock (ceiling).
10
Pull the wires through the strain relief and tighten the
strain relief screws.
Attach existing ducting to duct connector. Tape joints.
If ducting does not fit securely,
an adapter may need to be purchased.
Move the housing into position above the ceiling.
41788-01 6/1/2005
Connect the wiring.
To Next Page
