Hunter Bennett Series User Manual

6
1886
Installing the Motor Housing
Ceiling Bracket Hanging Fan Wiring Motor Housing Blades Light Remote Troubleshooting
Installing the Blades:
Insert grommets found in the hardware bag into the
holes in the blades, then secure each blade to a blade iron
with screws found in the hardware bag.
Repeat x5
Lightly attach the blade irons to the motor with
screws found in the hardware bag, then
securely tighten after both screws are attached.
Assembling the Light
Installing the Bulb and Glass
1
STEP
2
STEP
Raise the motor housing up over the motor and ceiling
bracket. Turn the motor housing so the screw holes align
and the indentation in the housing locks into place with
the notch in the ceiling bracket. The motor housing is
not secured until the next step is complete. Do not
leave unattended.
With a Phillips head screwdriver, install
the four motor housing screws found in
the hardware bag. Tighten all four
screws securely.
x4
bag
Notch
Indentation
Motor Housing
Screw
x15
bag
Blade Screw
x15
bag
Grommet
Repeat x5
x10
bag
Blade Arm Screw

Hunter Bennett Series Specifications

General

Type	Ceiling Fan
Blade Span	52 inches
Mounting Type	Downrod
Motor Speed	3 speeds
Material	Wood
Warranty	Lifetime
