Hunter Dempsey User Manual

2
1886
1886
Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
x4
x2
x2
x3
x3
x1
For installing the hanger bracket and wiring the fan
For installing the blades
For installing the canopy
For installing the light kit
Motor
Canopy
Canopy
Screw
Top Housing
Screw
Grounding
Screw
Ceiling Bracket
Canopy Trim Ring
Wood Screw
Wire Nut
Washer
bag
Hunter Pro Tip:
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.
Here is what comes in your box:
bag
M0230-01 r042519
Spare Parts
For your convenience,
you may receive extra fasteners.
bag
Remote Components
Remote Control
Remote Receiver
Remote Cradle
Upper Motor Housing
x12 x12
Blade ScrewBlade Washer
bag bag
x4
Blade
Glass
Upper Switch Housing
Light Kit Assembly
x6Light Kit Screw
bagx2

Hunter Dempsey Specifications

General

Type	Household blade fan
Placement	Ceiling
Fan diameter	1320.8 mm
On/off switch	Yes
Product color	White
Number of speeds	-
Number of fan blades	4
Power consumption (typical)	61 W
Bulb type	LED
Bulb power	9.8 W
Lamps quantity	1 lamp(s)
Number of bulbs	2 bulb(s)
