Hunter Dempsey User Manual

7
1886
1886
Ceiling Bracket Hanging Fan Wiring Canopy Blades Light Bulbs Remote
Assembling the Switch Housing
WARNING
FAN FALL HAZARD
Make sure the hood is securely attached to the mounting
plate. Failure to properly secure all 3 assembly screws could
result in the switch housing xture falling.
Screw two housing assembly screws from the
hardware bag halfway into the motor housing. It
does not matter which two screw holes you choose.
Feed the wire plug through the center hole of the
hood, then wrap keyhole slots around the screws
and twist counterclockwise.
Insert the third screw, found in the hardware
bag, into place and then tighten all three screws.
2 of 6
Light Kit Screw
bag
1 of 6
Light Kit Screw
bag
Assembling the Light Kit
Install the third switch housing screw. Tighten all
three screws securely.
Connect the plugs from the upper and lower
switch housings. Make sure to line up the
colored markings on the connectors.Wrap light
kit keyhole slots around the screws and twist
counterclockwise.
Screw two housing assembly screws from the
hardware bag halfway into the upper switch
housing. It does not matter which two screw holes
you choose.
2 of 6
Light Kit Screw
bag
1 of 6
Light Kit Screw
bag
WARNING
FAN FALL HAZARD
Make sure screws are tight to secure the
light xture.
Tab
Notch
Install a bulb into each of the sockets. When
necessary, replace with bulbs of the same
type and wattage.
WARNING
GLASS FALL HAZARD
To prevent SERIOUS INJURY or DEATH, make
sure that glass is properly secured.
Lift the globe and align the notches in the
globe with the tabs in the light kit. Attach
the glass bowl to the light kit by twisting it
clockwise until it snaps into place.

Hunter Dempsey Specifications

General

Type	Household blade fan
Placement	Ceiling
Fan diameter	1320.8 mm
On/off switch	Yes
Product color	White
Number of speeds	-
Number of fan blades	4
Power consumption (typical)	61 W
Bulb type	LED
Bulb power	9.8 W
Lamps quantity	1 lamp(s)
Number of bulbs	2 bulb(s)
