Reversing the Fan
Reverse
Switch
Ceiling fans work in two directions: downdraft
(counterclockwise rotation) and updraft
(clockwise rotation). To change the direction
of air ow, turn the fan off and let it come to a
complete stop. Slide the reversing switch to the
opposite position. Restart the fan.
Updraft (clockwise rotation)
creates a more indirect airow.
Updraft airow is great for
moving warm air downward.
Downdraft (counterclockwise
rotation) creates a direct
breeze and maximum cooling
effect.
Fan style may vary.
Note:
Ceiling Bracket Hanging Fan Wiring Canopy Blades Control
ON
Turn Power
Fan style may vary.
Note:
Repeat x2
Connect the appropriate pull chain
pendant to each of the short chains
coming from the nial and nial cap.
The fan pull chain controls
the speed: from high to off.
The light pull chain controls
the light xture: on and off.
Installing the Pull Chains
