4
Dial Marking Measurement Unit
X0.01 0.01 gallon
X0.1 0.1 gallon
X1 1 gallon
X10 10 gallons
X100
100 gallons
Note: The ow meter will read in U.S on
the dial. You can change the units in the
app to gallons (gal) or liters.
HC Flow Meters
The ow meter consists of two parts:
1. Flow meter body: The ow meter body contains an analog dial for manual
readings as follows. Your ow meter will have three wires protruding from the
ow meter’s body. The wires need to be connected to the sensor inputs on
the controller for remote measurement. In all models, only two wires (blue and white) are used.
2. Adapter: Each ow meter has an adapter to allow connection to your irrigation system.
