Feed the wire plug through the center
hole of the upper switch housing, then
wrap keyhole slots around the two screws
and twist counterclockwise to lock the
upper switch housing into place.
Partially install two switch housing
assembly screws ,found in
the hardware bag, into the motor
housing as shown. It does not matter
which two screw holes you choose.
Insert the third screw, found in
the hardware bag, into place and
then tighten all three screws.
Make sure the upper switch housing is securely
attached to the mounting plate. Failure to properly
secure all 3 assembly screws could result in the switch
housing xture falling.
Switch Housing & Light Kit (continued)
Switch
Housing
Assembly
Screw
14
