2
For installing the blades
Blade Arm
Blade
Blade Arm Screw
x10
x5
x5
bag
x15 x15
Blade Washer
bag bag
x4
x2
x2
x2
x2
For installing the hanger bracket and wiring the fan
For installing the canopy
For installing the light xture
Bulb
Glass
Light Fixture Hood
Light Fixture
Light Fixture Cage
Downrod
Motor
Canopy
Canopy Screw
Ceiling Bracket
Wood Screw
Wire Nut
Washer
bag
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it
right. Visit us at HunterFan.com or call us at
1.888.830.1326.
bag
Spare Parts
For your convenience,
you may receive extra fasteners.
bag
Fixture Mounting Screw
Fixture Screw
x3
x6
bag
M3697-01 r042518
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
Here is what comes in your box:
Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
Hunter Pro Tip:
Remote Components
Remote Control
Remote Receiver
Remote Cradle
To Next Page
