3
4
Check the outlet box:
Wood Screw
Installing the Top Housing
8”
3/8”
C
U
T
&
S
T
R
I
P
(not to scale)
Top Housing
Screw
Grounding
Screw
bag
The wires can be cut, but
leave at least 8” extending
from the top of the canopy.
Install the third canopy screw and
grounding screw which can be found
in the
hardware bag. Tighten
all screws.
Grounding
Screw
To prevent damage to fan,
ALWAYS lift holding the fan
housing.
Note: To hang the fan, you must tilt the canopy to
an almost vertical position so that the canopy slots
sit on the ceiling plate hooks.
Raise the fan and align the slots in the
canopy with the hooks on the ceiling plate.
Place the slots over the ceiling
plate hooks to hang the fan.
Fan style may vary.
Note:
Ceiling Bracket Hanging Fan Wiring Canopy Blades Wall Control
