HunterDouglas M40 TE - WARNINGS FOR DAILY USE OF THE AUTOMATION; Maximum continuous work cycle

8 – English
EN
EC declaration of conformity
HunterDouglasherebydeclaresthattheproducts:M40TE324,M40TE524,
M40 TE 611, M40 TE 1011, M50 TE 426, M50 TE 1026, M50 TE 817, M50
1517, M50 3017, M50 4012, M50 5012 conform to the essential requisites
and other pertinent provisions laid down by directives 2006/95/CE (LVD) e
2004/108/CE (EMC).
N.Dekker
(manager Reserch and Development)
Power supply voltage:230Vac-50Hz
Power absorption on standby: 0,5 W
Encoder resolution: 2,7°
Continuous operation time: 4 min
Connection cable length: 2,5 m
Operating temperature: -20°C
IP Protection rating:IP44
Note:
– All technical characteristics refer to an ambient temperature of 20°C (± 5°C).
–HunterDouglasreservestherighttoapplymodicationstotheproductatany
ti me when deemed necessary, while maintaining the same functionalities and
in tended use.
Technical specications
What to do if …
(troubleshooting guide)
6.1 - Maximum continuous work cycle
Ingeneralthetubularmotorsinthe“Max”range,whileguaranteeingamaximum
continuous use of 4 minutes, are designed for residential applications and therefore
fordiscontinuoususe.Thereforeintheeventofoverheating(forexampledueto
continuous and prolonged activation ) a thermal cut-out trips automatically to shut
off power supply. Power is only restored when the temperature returns to within the
normal range.
WARNINGS FOR DAILY USE OF
THE AUTOMATION
6
q When an electric phase is powered, the motor does not move:
 Unlessathermalcut-outhastripped,inwhichcaseitissufcienttowaitforthe
motor to cool, check that the mains power voltage corresponds to the data stat-
edinthetechnicalspecicationsinthismanual,measuringtheenergybetween
the “common” wire and that of the powered electric wire. Then try and power the
opposite electric phase.
q When an up command is made, the motor does not start:
 Iftheawningisalreadyclosedornearlyclosed,themotordoesnotperformthe
upmanoeuvre.Inthiscasemovetheawningdownslightlyandthenrepeatthe
up command.
q The system operates in emergency hold-to-run conditions
 –Checkwhetherthemotorhasbeensubjecttoasevereelectricalormechanical
shock.
– Check that all motors components are intact.
– Perform the deletion procedure (paragraph 5.9) and programme the limit
switches again.
Disposal of the product
This product constitutes an integral part of the automation system, there-
fore it must be disposed of along with it.
As in installation, also at the end of product lifetime, the disassembly and scrapping
operationsmustbeperformedbyqualiedpersonnel.
This product is made up of different types of material, some of which can be recycled
whileothersmustbedisposedof.Seekinformationontherecyclinganddisposal
systems envisaged by the local regulations in your area for this product category.
Caution! - some parts of the product may contain pollutant or hazardous substanc-
es which, if disposed of into the environment, may cause serious damage to the
environment or physical health.
As indicated by the symbol on the left, disposal of this product in
domesticwasteisstrictlyprohibited.Separatethewasteintocate-
gories for disposal, ac cording to the methods envisaged by current
legislation in your area, or return the product to the retailer when pur-
chasing a new version.
Caution!-Locallegislationmayenvisageseriousnesintheeventofabusivedis-
posal of this product.
