HUROM H-310A - Assembly and Disassembly of Silicone

˟4JMJDPOFQBDLJOHTBSFTVQQPTFEUPCFSFQMBDFEFWFSZ
UPNPOUIT:PVDBOQVSDIBTFUIFNUISPVHIPVS
$VTUPNFS4FSWJDF$FOUFS
01
02
03
(The juicer may leak if the product is not assembled
properly.)
Hold the silicone ring and pull it out smoothly.
After cleaning, plug the silicone ring upright into the
slot by fixing one end into place first.
Insert the rest and press down firmly
Extraction Packing
Seal Packing
After cleaning, firmly insert with the round side outward and
the grid hollow facing upward.
Assemble the packings as shown in the figure.
Juice Cap Packing
Hopper Packing
01
02
03
Grab onto one side and pull out.
After cleaning, check the top and bottom direction of
the packing and insert it upward as if you hook it on the
bottom of the multi-screw.
After checking the direction, press the rest of the
packing down without any folded part.
Screw Packing
6. Assembly and Disassembly of Silicone
01
02
01
02
English
09
