DISASSEMBLING AND CLEANING THE CHAMBER
Open juice cap first. Hold the chamber and juice cap with one hand and peel off the juice cap seal with the other hand.
Remove the chamber seal by pinching and twisting it off with two fingers.
Wash chamber and chamber seal with cleaning
brush under the running water.
16 l
1
Remove the juice cap seal and the chamber seal.
2
Open the extraction seal at the bottom of
the chamber.
3
Wash the chamber and all the seals.
juice cap
seal
chamber
seal
Extraction
Seal
