SPEED ADJUSTMENT
Set desired speed by pulling the pull switch (A).
0---Stop 1---Low 2---Medium 3---High
OSCILLATION CONTROL
Adjust the angle of oscillation by pulling the pull
switch (B). Then, push the guard lightly up or down
to reach the desired position.
USER-SERVICING INSTRUCTIONS
1. Grasp the plug and remove it from the
receptacle or other outlet device.
DO NOT unplug by pulling on the cord.
2. Open the fuse cover. Slide open the fuse
access cover on top of the attachment
plug, toward the blades.
3. Remove the fuse carefully. Push the fuse from the other side or turn the
fuse holder over to remove the fuse.
4. Warning: Using the wrong voltage fuse can lead to risk of fire. Replace
the fuse only with a 2.5 A, 125 volt fuse.
5. Close the fuse cover. Slide the fuse access cover on top of the attachment
plug to the closed position.
6. Warning: risk of fire. DO NOT replace attachment plug. Contains a
safety device (fuse) that should not be removed. Discard product if the
attachment plug is damaged.
1. Be sure to unplug from the power source before cleaning.
2. Plastic parts should be cleaned with mild soap and damp cloth or sponge.
Thoroughly remove soap film with clean water.
3. Be sure not to let water or other liquid enter the inside of the motor.
CLEANING
(A)
(B)
Manufactured for Hawthorne Hydroponics LLC, a
subsidiary of The Hawthorne Gardening Company,
3204 NW 38th Circle, Vancouver, WA 98660
HawthorneGC.com | Canada: HawthorneGC.ca
©2019. World rights reserved.
16” OSCILLATING WALL MOUNT FAN
Product No: #736503
